Sterner Automation Delivers a Flexible Communication Interface
for Testing

Today's automotive applications demand flexible integration tools to ensure test equipment can meet changing technological and communication requirements. Sterner Automation has developed the next generation of testing interface solutions specially designed to address multiple technologies, including occupant classification systems (OCS). The Sterner interface box (SIB) provides our customers with the capability to efficiently operate, monitor and report on end-of-line (EOL) test equipment anywhere in the world.

The Sterner SIB Guarantees Seamless Communication

  • Provides a universal interface between the electronic control unit (ECU) and EOL testers
  • Supports RS232 or ethernet connection to EOL testers as well as ethernet connection to factory information systems (FIS)
  • Delivers flexible control of the test process sequence and can function as a master, simple slave or process aware slave
  • Allows access to the ECU variables through memory or tag (PID, DID messages)
  • Tests, emulates and performs data acquisition for ratio-metric, voltage and current output sensors, including pressure sensors, belt tension sensors (BTS), seat belt buckle switches (SBBS) and seat track position sensors (STPS)
  • Capable of customizing test process sequences and performing custom test calculations and algorithms
  • Sterner Automation's proprietary vehicle electronic serial interface (VESI) supports all major automotive communication protocols
  • Compatible with PLC or PC-based controls and features a quick reference diagnostic and test result LCD readout
  • Rugged rack mount enclosure with carrying handles and standardized connectors allow for simple installation
  • Remote access, using telephone modem or internet, provides immediate diagnosis and software updates
  • User-friendly USB port application allows for local software upgrades and traceability data transfer
  • Optional local database storage is available for traceability requirements

The Sterner SIB Improves Efficiency

  • Reduces costs by providing single source test and communication integration
  • Maintains production efficiency with remote diagnostics and 24-7 service support
  • Adapts to required changes and upgrades throughout the SIB life cycle
  • Minimizes setup and downtime

This high-performance communication tool can meet your current and future test interface requirements.

Sharpen your competitive edge by integrating Sterner Automation solutions into your production process today!

Specifications



Mechanical Systems

Enclosure

·         Heavy-duty

·         Durable powder coat finish

Form Factor

·         2RU



Electrical Systems

Input Voltage

·         95-264 VAC full-range input

Frequency

·         47-63 Hz

Input Current

·         5 A



Processing Hardware

Processor

·         Intel Pentium-M 1.6 GHz

Memory

·         512 MB DDR

Hard disk

·         40 GB

Modem

·         56 Kbps

Ethernet

·         2 × 10-100 Mbps



Software Systems

  • Microsoft Windows XP Professional
  • PCAnywhere



Vehicle Communication Protocols

  • Dual wire and single wire CAN
  • GMLAN
  • UART
  • Class 2/J1850 (VPW)
  • LIN
  • Keyword 2000



External connectors

·         1 - A/C Power inlet

·         2 - RJ-45 for Ethernet

·         1 - RS-232 serial port

·         1 - PS/2 keyboard port

·         1 - PS/2 mouse port

·         1 - HD-15 video connector

·         1 - RJ-11 modem connector

·         1 - BNC coaxial connector

·         1 - External A/D hardware trigger input

·         2 - USB 2.0 ports

·         1 - DB-15 vehicle ECU communications port

·         1 - 16-pin digital I/O connector for remote / PLC synchronization



Service Support

  • All instrumentation and software are programmed and tested prior to shipment
  • Electronic operator manual and instructions are included for reference
  • 24-7 emergency service hotline ensures maximum support



Options

  • Analog-to-digital converter with 16 bit, 200 ksps A/D converter and 1 K samples hardware FIFO buffer
  • Local traceability database
