Your PCB Manual Assembly Solution
The continued trend toward greater product complexity and zero defect production is increasing demands
on electronics assembly personnel. Sterner Automation's new igentic® 313i, the first in a series of intelligent
electronic instruments, is specially designed to address these complex printed circuit board (PCB) assembly
and testing requirements. The igentic® 313i guides your operators through each step of the assembly process
with an interactive electronic and visual check system, ensuring your operators can consistently deliver the
quality needed to meet the highest of standards.
The igentic® 313i has the Flexibility to Meet All Your Assembly Needs
- Configurable test station is specially engineered for the verification of light emitting
diodes (LEDs), resistors, capacitors, diodes and transistors, ensuring that the system
can handle the majority of manually assembled parts
- Add-on custom station can be integrated and tooled for other component requirements
- Test-to-light system guarantees the correct part type and orientation prior to part insertion
- Unique integrating sphere maximizes the reliability of LED colour and intensity verification
- Flexible ergonomic layout and bracket system accommodates diverse operator needs
- Simple to retrieve transactional work instructions (TWI), featuring error-proofing logic, guarantee assembly operations are completed correctly and in sequence
- Foot pedal program advance, ensures operators can maintain efficiency
- Plug-and-play connectors with pick-to-light cable system allow for the integration of existing component bins
- User-friendly software utilizes colour-coded pictorial templates to assist in the rapid programming of instruction sets
- All software is compatible with standard Windows operating systems and industry peripherals allowing for simple integration with existing work stations
- Optional PCB barcode scanning and operator identification provide product traceability
- Multi-language compatibility meets global corporate requirements
The igentic® 313i Delivers Reliable Single Piece Build
- Provides versatility, allowing for use in kitting, new product introduction (NPI), assembly and rework applications
- Improves overall product quality and customer satisfaction
- Facilitates just-in-time delivery and single piece build
- Increases profitability by maximizing first pass yields
- Shortens the time needed for new product introduction
- Reduces setups and assembler training
- Easily justified based on multi-application capabilities and overall value
This intuitive system gives you error-free production,
maximum flexibility
and enhanced profitability through all stages of your production
cycle.
Sharpen your competitive edge by integrating Sterner Automation
igentic® solutions into your production process today!
|
Specifications
Configuration
Module
|
Station type
|
Tests
|
Module 1
|
Test
|
·
Resistors
·
Capacitors
·
Small footprint inductors
|
Module 2
|
Test
|
·
LEDs
|
Module 3
|
Test
|
·
Transistors
·
Diodes
|
Module 4
|
Custom
|
·
Large footprint electrolytic
capacitors
·
SIP resistors
·
Other custom components
|
Performance Characteristics
LED Testing
|
·
Tests standard intensity and ultra-bright LEDs
·
Verification of anode/cathode orientation
·
Forward voltage (0 to 10 V) with 0.5% basic accuracy
·
Colour comparison in the visible light spectrum using HSL colour space
·
Forward test current is adjustable between
0 mA to 50 mA in 1 mA steps
·
T 1 ¾ (5 mm) and T 1 (3 mm)
·
Square LEDs with maximum 8 × 8 mm body
|
Transistor Testing
|
·
NPN and PNP transistors
·
VCE, VEB, VCB, IB, IC, and
HFE with the basic accuracy of 0.5%
·
C, B, E pin detection of switching, GP amplifier, and high-frequency transistors
·
MT-1, MT-2, MT-3, MT-4, TO-92,
TO-218, TO-220, TO-225, TO-247, TO-264 transistor packages
·
Maximum pin diameter 0.863 mm
(0.034") (Can be customized for larger pin diameters)
|
Diode testing
|
·
Silicon and germanium diodes
·
Anode/cathode orientation
·
Forward voltage (0 to 10 V) with 0.5% basic accuracy
·
Zener voltage measurements up to 20 V with 0.5% basic accuracy
·
Maximum forward test current of 10 mA
·
Diode packages C-16, DO-15, DO-35, DO-41, DO-201, DO-204, DOP-31, SOD-93, T-18 and
any two lead axial package with the maximum pre-formed lead spacing of 28 mm
|
Resistor Testing
|
·
Resistors of value between 1 Ω and 10 MΩ with 3% basic accuracy
·
Axial body type with lead spacing of 28 mm maximum
|
Capacitor Testing
|
·
Radial and axial lead capacitors of values between 10 pF and 2200μF can be tested
with 3% basic accuracy
·
Maximum lead spacing of 28 mm
|
Software Systems
-
Microsoft PowerPoint
based programmable software – minimum version 2000
-
Minimum operating system
– Windows 2000
Mechanical Systems
Enclosure
|
·
Heavy-duty
·
Durable powder coat finish
·
Integrated brackets for
slide line or conveyor mounting
|
Test sockets
|
·
Precision quick-change
·
Stainless steel compliant
contacts
|
Custom module
|
·
Heavy-duty
·
Powder coat finish
·
Coupling system for integration
with main test station
|
Service Support
-
All instrumentation and
software are programmed and tested prior to shipment
-
Electronic operator manual
and instructions are included for reference
-
24-7 emergency service
hotline ensures maximum support
Interface Requirements
-
Power requirement – 100-240
VAC auto-switching, 3 A, 50-60 Hz external desktop power supply
-
USB computer communications
interface
Options
-
System compatible integrated
PC and touch screen display
-
Interface barcode scanner
for part and assembler badge identification
-
Lead trim and forming
module
-
Replacement pick-to-light
cables and test sockets
-
Customized data collection and factory information system (FIS) integration
| |
